EG4 6000XP + Eco-Worthy Battery Communication Setup (CAN Bus Guide)
Troubleshooting note from this video
🔗 Links Mentioned
Affiliate link — we may earn a commission if you purchase through this link, at no extra cost to you.
📝 Description
Affiliate link — we may earn a commission if you purchase through this link, at no extra cost to you.
6000xp: https://signaturesolar.com/eg4-6000xp-off-grid-inverter-split-phase/?ref=bkpkbxde
12000xp: https://signaturesolar.com/eg4-12000xp-off-grid-inverter-48v-non-feoc?ref=bkpkbxde
How to Connect an Eco-Worthy Battery to an EG4 6000XP
Fix EG4 6000XP Battery Communication in 60 Seconds
Eco-Worthy Battery + EG4 6000XP Setup Tutorial
EG4 6000XP Battery Comms Working! Here's How
Eco-Worthy 314Ah Battery CAN Bus Setup for EG4
How to Enable Battery Communication on an EG4 6000XP
How to Enable Battery Communications Between an Eco-Worthy 314Ah Battery and an EG4 6000XP Inverter
In this quick tutorial, I show how to connect an Eco-Worthy 314Ah LiFePO4 battery to an EG4 6000XP inverter using CAN Bus communication.
This same process also works for the EG4 12000XP, although the menu navigation is slightly different.
Steps covered:
Connect Ethernet cable to the battery CAN port
Connect CAN cable to the EG4 BAT COM port
Set battery address DIP switch to Address 1
Configure battery CAN protocol to Lux Power
Configure EG4 battery type to Lithium
Set battery brand to Lux Power
Verify battery communication and State of Charge reporting
Once configured correctly, the inverter will display battery percentage, battery status, and communicate directly with the battery BMS.
Products shown:
Eco-Worthy 314Ah LiFePO4 Battery
EG4 6000XP Inverter
EG4 12000XP Inverter
#eg4 #ecoworthy #6000xp #12000xp #solarbattery #lifepo4 #offgrid #solarbattery
Eco-Worthy 314Ah LiFePO4 Battery
Specification Value
Battery Type LiFePO4
Capacity 314Ah
Communication CAN Bus
Address Selection DIP Switch
Protocol Used Lux Power
BMS Communication Supported
EG4 6000XP
Specification Value
Model EG4 6000XP
Battery Communication CAN Bus
Battery Port BAT COM
Lithium Battery Support Yes
Protocol Support Lux Power
Off-Grid Inverter Yes
EG4 12000XP
Specification Value
Model EG4 12000XP
Battery Communication CAN Bus
Protocol Support Lux Power
Lithium Battery Support Yes
batterycommunicationecoinverterworthybushowluxpowercomconnectprotocolsupportaddressgrid
🎬 Related Videos
📝 Video Transcript
Hey, what's up, guys? I'm going to show you how to set up uh communications between this EG4 worthy uh 314 amp hour battery and this EG4 6000 XP inverter. These instructions will also work for the 12000 XP. You just have to use the interface a little bit differently.
First thing we're going to do is we're going to come around here. We're going to get a standard ethernet cable and we're going to connect this ethernet cable to this port here that's called CAN. And then we're going to set the battery address to uh one, which means the first dip switch is going to be up and all the other dip switches are going to be down. Using that ethernet cable from CAN, we're going to connect to this port right here, which is bat com, which is uh the port on the far left.
Then we're going to go to this screen inside the battery. We're going to go to CAN, select CAN, then you're going to select Luxpower. Once you select that, you'll have an option to save. You're going to save that.
Uh I've already done that in this case. And then you're going to go to this inverter setting. You're going to go uh hold the enter button down for about 4 seconds, 3 to 4 seconds. You're going to go to option three, hit enter, and then once it goes there, it's going to tell you uh you're at the battery option, right?
So then you're going to hit enter. And it's going to say type lithium ion. Assuming we can get this thing to focus right here. Type lithium ion.
Then we're going to select enter, and then we're going to go to battery brand, and we're going to select six because six is uh Luxpower according to this. So we're going to go ahead and hit enter. Once you hit enter, the inverter will reset, and then it'll come up with the battery communications working as you can see right here. 99% battery, battery is full, lithium ion.
As you can see right here, if you go all the way back out, this is going to also be 99% full, and now battery communications is working between this battery and this inverter.
